Active Points Report Screen Printing Reports
IFC-3030 Operations Manual — PN 52026:C 08/05/2005 59
5.4 Active Points Report Screen
This screen displays when the ACTIVE POINTS soft key is pressed on the PRINTER
FUNCTIONS screen (refer to Figure 5.1 on page 55).
Figure 5.4 Print Active Points Screen
Soft Keys
This screen provides a menu for printing a list of active points for whatever type of list is chosen.
The soft key will display on the screen only if there is at least one event in the queue.
Note: For a printed list of history information, refer to the history screens in Section 4, "Viewing
and Printing History Information".
5.5 Installed Points Report Screen
This screen displays when the INSTALLED POINTS soft key is pressed on the PRINTER
FUNCTIONS screen (refer to Figure 5.1 on page 55)
Figure 5.5 Print Programming Screen
Soft Keys
SLC POINTS:Press to print information on installed SLC points. When the soft key is pressed, a
field appears to allow choice of a single SLC or ALL. Toggle until the desired choice appears in
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
ACTIVE POINTS
ALARMS ONLY PREALARMS
TROUBLES ONLY DISABLED POINTS
SUPERVISORY ALARMS ACTIVATED OUTPUTS
SECURITY/OTHER BACK
INSTALLED POINTS MENU
SLC POINTS RELEASING ZONES
PANEL CIRCUITS SPECIAL ZONES
GENERAL ZONES TROUBLE ZONES
LOGIC ZONES RANGE
ACS BACK
