4.3 Point Range Select for All Events in Range
Pressing the Point Range soft key on the Local History Select screen displays the Point Range
Select screen. This screen allows for selection of a beginning and an end point that defines the
range of events to be viewed and/or printed.
Range is selected in the following order:
1. Loop 1 Detectors
2. Loop 2 Detectors, etc...
3. Loop 10 Detectors
4. Loop 1 Modules
5. Loop 2 Modules, etc...
This FACP can have up to 10 loops, which would all follow the above order for range selection.
1. Loop 10 Modules
2. Panel Circuits
The range selected below includes all supervisory event types for every point: the selection begins
with the first detector on loop one and ends with the last panel circuit.
Figure 4.3 Point Range Select Screen
Display
See description in "Events History" on page 51 for lines 1-5.
Soft Keys
START POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter a start
point for event viewing.
END POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter an end
point for event viewing.
EVENT TYPE: - Press this soft key to scroll through the following: ALL EVENTS, ALARMS
ONLY, TROUBLES ONLY, SUPERVISORY ONLY, SECURITY ONLY, OTHER ONLY. Stop
scrolling at the desired event type.
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Range
Screen.
All Events in Range Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page
51.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A WED AUG 25, 2004
POINT RANGE SELECT
START POINT:
L01D001 (DETECTOR)
END POINT:
P12.8 (MODULE)
EVENT TYPE: SUPERVISORY ACCEPT
BACK
