The following accessories for the FIT can be ordered separately:
Table 1. Products and Accessories
Code Number Description
MS-FITCASE-0 FIT carrying case; includes one soft-sided carrying case
FX-BTCVTCBL-700 FIT cable replacement; includes one 5 ft. (1.5m) retractable
cable
Physical Features
The FIT is a portable handheld device. It is powered by two AA Alkaline batteries
through the on/off power switch. The LCD display is a two-line by eight-character
display with backlight, and the keypad consists of four keys. A Four-Pin removable
terminal block, and the RJ-12 connector cable provide the interface to the MS/TP
bus. The FIT also has a Micro-USB port, which is used to update the firmware and
extract report data. See Figure 1.
Figure 1. FIT Physical Features
All the keys on the FIT have a repeat function in which the key action is
repeated when the key is held down for more than one second. For example, if you
hold down the Down Arrow Key, the cursor field moves down one selection each
half second. The repeat rate is the same for all the keys.
General Use and Information
FIT User Guidelines
Note:
