FIT Display Table
Table 1. FIT Display Table
Menu
Fit
Display Short Meaning
Expert
Mode Description
Health Bus
Health
Bars
Health of a Bus An overall indication of Bus Health.
8 is desired, but 4 is the minimum.
ScanBus ScanBus Force a Bus
Scan
Main Menu item. Used to initiate,
monitor & interrogate controllers
on the FC/SA bus.
ScanBus Scan Devs Quantity of
Addresses
Found
Displays the quantity of nodes
talking on a bus.
ScanBus Adr Bit Volts
Reading at
Address
Address reported by the controller.
Scanbus BitVolts Bit Volts
Reading at
Address
Communication Voltage reported
by the Address.
ScanBus EOL
FC EOL
FC Bus: EOL
Switch Position
at Address
SA Bus: FC
Address and
EOL Switch
Position
When connected to a FC Bus this
shows the Position of the End-Of-
Line Switch reported at address.
When connected to a SA Bus this
shows the FC Bus Address and the
Position of the End-Of-Line Switch
reported at address.
ScanBus Model Model Name at
Address
Device object Model Name
property for device at address
ScanBus Ver Firmware
Version at
Address
X The version of the Firmware
loaded in the controller at this
address.
ScanBus Name Device Name at
Address
Device object Object_Name
property for device at address
