Menu
Fit
Display Short Meaning
Expert
Mode Description
ScanBus OID Device Object
ID
X The BACnet device ID for the
scanned controller. This is set by
the application file in the
controller and are not necessarily
unique.
ScanBus Vendor Device Vendor
at Address
X Device object Vendor property for
device at address
ScanBus Desc Device
Description at
Address
X Device object Description property
for device at address
Issues Issues Bus Issues Menu
Item
Main Menu item. Select to see
quantity, history, and history
details of Issues.
Issues Issues Quantity of
Issues recorded
Quantity of potential Issues
discovered by the FIT.
Issues Online Device Came
Online
Most current Issue (no leading
number). In this case, a controller
came on line after initial FIT token
loop was complete.
Issues n Issue
Type
Historical Issue
number and
Type
Where n represents a historical
issue, Issue Type is either Online,
Offline, Badframe, ChrFrame,
2ndTkn or EOL>2
Issues TKN Token Represents the Token (TKN)
passing from one address to the
next.
Issues Badframe Bad Data
Received
Bad Data Received. Bad MS/TP
frame. Invalid MS/TP header CRC
or data CRC.
Issues ChrFrame Character
Framing Error
Characters are transmitted in
frames. If a frame is too long or
short, a framing error occurs.
Issues 2ndTkn Token Re-
transmitted.
A device handed off the token, but
no transmission seen. the TKN is
re-transmitted.
Issues Offline Device went
offline.
This device was online, received a
PFM, and did not reply to it.
