1/7/2021 PDF Export
https://docs.johnsoncontrols.com/bas/internal/api/webapp/print/b4118696-0b8a-4733-98fb-fdd04b065b15 32/60
Table 1. Voltage Table
Voltage
Communication
State Meaning Acceptable Range
1
Bias Voltage Either Idle or
Active
Communication
The + to COM
Reading, - to COM
or + to -. Typically
used such as + is
biased to com, -,
etc. It is the
voltage applied to
the bus by the EOL
termination on the
controller to
establish a
properly biased
bus.
See notes below for
acceptable ranges based
on active or idle
communication states.
Idle Voltage Idle The term idle
voltage could be
referring to + to
COM, - to COM or
the + to –
(differential)
Reading. What it
really means is no
communication is
occurring at the
time of the
reading.
Typically near 2.7 (+ to
com) -2.3 VDC (- to com)
with a differential (+ to -)
of 0.4VDC. Can vary with
wire length & bus load but
should not be lower than
~0.2VDC differential or
higher than ~0.9VDC
differential.
Idle Differential
Voltage
Idle This is typically
referring to the +
to – voltage
reading without
communication.
~0.2 to ~0.9 VDC
Communication
Voltage
Active The term
communication
voltage could be
referring to + to
COM, - to COM or
the + to – Reading.
Communication is
occurring at the
time of the
reading.
See Bit Voltage and
Differential Voltage below.
