RDR2S-A and I8O4 Hardware Installation Description of Signals
24-10239-596 Rev. D
9
Figure 5: I8O4 Terminal Blocks Outline
TERMINAL 1
PANEL S300 BUS
TERMINAL 1 TERMINAL 2 CAL POWER
I8O4
TERMINAL 1 TERMINAL 2
TERMINAL 2
