Johnson Controls S300 Series Hardware Installation

RDR2S-A and I8O4 Hardware Installation Introduction
24-10239-596 Rev. D
1
HARDWARE INSTALLATION
This document provides hardware installation instructions for the
S300-DIN-RDR2SA and the S300-DIN-I8O4.
I
NTRODUCTION
The S300-DIN-RDR2SA and S300-DIN-I8O4 modules provide interface
control for access and security devices associated with up to two doors.
NOTE: Throughout this manual the S300-DIN-RDR2SA module is also referred
to as the RDR2S-A, while the S300-DIN-I8O4 module is referred to as the I8O4.
S300-DIN-RDR2SA Module
Figure 1: S300-DIN-RDR2SA

Johnson Controls S300 Series Specifications

General

Brand	Johnson Controls
Model	S300 Series
Category	Control Unit
Language	English
