Johnson Controls S300 Series Hardware Installation

RDR2S-A and I8O4 Hardware Installation Setup and Adjustments
24-10239-596 Rev. D
35
Output Point Signals
Table 8: RDR2S-A and I8O4 Output Points
Application-Specific Use
1
(RDR2S-A
only)
1. Physical or legacy address mode.
General Purpose Use
2
(RDR2S-A with I/O
disassociation or I8O4)
2. Physical address mode only (CK721-A version 3.0 or higher, and CK722).
“Reader n Red LED”
Application Specific Output
Output is set every time
access deny occurs.
Output is an open collector
that switches to ground.
“Terminal n OUT1”
General Purpose Output
It can be timed, set, reset, fast
flash, or slow flash.
Output is an open collector
that switches to ground.
“Reader n Green LED”
Application Specific Output
Output is set every time
access grant occurs.
Output is an open collector
that switches to ground.
“Terminal n OUT2”
General Purpose Output
It can be timed, set, reset, fast
flash, or slow flash.
Output is an open collector
that switches to ground.
“Reader n Shunt”
Application Specific Output
Output is set every time
access grant occurs.
Output is a relay.
“Terminal n OUT3”
General Purpose Output
It can be timed, set, reset, fast
flash, or slow flash.
Output is an open collector
that switches to ground.
Output is a relay.
“Reader n Strike”
Application Specific Output
Output is set every time
access grant or request to
exit occurs.
Output is a relay.
“Terminal n OUT5”
General Purpose Output
It can be timed, set, reset, fast
flash, or slow flash.
Output is an open collector
that switches to ground.
Output is a relay.
GREEN LED COM RED LED
READER n
LED
OUT2 COM OUT1
TERMINAL n
GREEN LED COM RED LED
READER n
LED
OUT2 COM OUT1
TERMINAL n
NO
COM
NC
READER n
SHUNT
NO
COM
NC
TERMINAL n
OUT3
NO
COM
NC
READER n
STRIKE
NO
COM
NC
TERMINAL n
OUT5
