RDR2S-A and I8O4 Hardware Installation Setup and Adjustments
24-10239-596 Rev. D
30
Table 5: Terminal Addressing for CK721-A (V3.0, Physical Address Mode) and CK722 Controllers
DIP Switch Number
1 234 5 6 7 8
Label on the Module
Hardware
Module #
Wiegand
RS485
EOL 124816
0
See page 14 See page 24
off off off off off
1 ON off off off off
2offON off off off
3 ON ON off off off
4offoffON off off
5 ON off ON off off
6offON ON off off
7 ON ON ON off off
8 off off off ON off
9 ON off off ON off
10 off ON off ON off
11 ON ON off ON off
12 off off ON ON off
13 ON off ON ON off
14 off ON ON ON off
15 ON ON ON ON off
16 off off off off ON
17 ON off off off ON
18 off ON off off ON
19 ON ON off off ON
20 off off ON off ON
21 ON off ON off ON
22 off ON ON off ON
23 ON ON ON off
ON
24 off off off ON ON
25 ON off off ON ON
26 off ON off ON ON
27 ON ON off ON ON
28 off off ON ON ON
29 ON off ON ON ON
30 off ON ON ON ON
31 ON ON ON ON ON
