Table 21: M-Bus protocol rules (bus topology)
Category Rules
General Two direct M-Bus connections to the USB port are supported.
Connection requires a USB-to-M-Bus adapter at the USB port
Either FC port supports M-Bus devices
No restrictions in topology, but bus topology is strongly recommended
Number of devices The MR003USB adapter supports up to 10 loads
The ACC-USBMBUS-0 adapter supports up to 100 loads
Length depends on cable resistance, capacitance, number of devices, position of
devices, and configured communication speed. Example scenarios to help with
calculation:
Baud rate
1
,
2
Maximum number
of unit loads
Maximum distance
between converter
and devices
Maximum distance
for entire bus
64 3,000 m (9,842 ft) 5,000 m (16,404 ft)
(2 mm x 1.0 mm
[18 AWG], shield
recommended,
resistance < 90
Ohms)
64 1,000 m (3,281 ft) 4,000 m (13,123 ft)
(2 mm x 1.0 mm
[18 AWG], shielded,
resistance < 90
Ohms)
250 350 m (1,148 ft) 4,000 m (13,123 ft)
(2 mm x 0.8 mm
[20 AWG], shielded,
resistance < 30
Ohms)
2400
250 350 m (1,148 ft) 4,000 m (13,123 ft)
(2 mm x 0.8 mm
[20 AWG], shielded,
resistance < 30
Ohms)
64 350 m (1,148 ft) 4,000 m (13,123 ft)
(2 mm x 0.8 mm
[20 AWG], shielded,
resistance < 30
Ohms)
9,600
250 350 m (1,148 ft) 1,000 m (3,281 ft)
(2 mm x 0.8 mm
[20 AWG], shielded,
resistance < 30
Ohms)
Line length and type
38,400 64 350 m (1,148 ft) 1,000 m (3,281 ft)
(2 mm x 0.8 mm
[20 AWG], shielded,
resistance < 30
Ohms)
Cable Twisted pair cable (shielding optional)
Termination No termination
1 Unit load is a defined standby current. A device is permitted a current drain of one unit load by default but may consume more if it
is shown at the device (as an integer) and in documentation.
SNE Installation Guide18
