Table 4: Supported integrations and adapters
Integration USB adapter required (Product code
number and description)
LonWorks ACC-USBLON-0
USB to LonWorks adapter
MR003USB
Mikro-Master USB to M-Bus adapter for
up to 10 M-Bus devices.
M-Bus
ACC-USBMBUS-0
USB-to-MBus level converter for up to
100 unit loads
Zettler Fire Panel ACC-USBRS232-0
RS232 USB adapter
Modbus RTU that
requires a RS-485 serial
connection
ACC-USBRS485-0
USB-to-RS485 Adapter
Important: Only the USB adapters listed in Table 4
function on the SNE. Other non-qualified adapters
do not function in the USB ports of the SNE, but
Johnson Controls will continue to qualify additional
adapters in future releases. Also, the USB ports do
not support external modems or USB network hubs.
Important: Do not connect any other loads to the
USB ports. For example, do not power cell phones
from the USB ports.
LonWorks network adapter
All SNE models except the SNE110Lx can integrate to the
LonWorks network with the addition of a separate USB-
to-LON interface adapter (ACC-USBLON-0). This required
adapter connects the network engine to the LonWorks
TP/FT-10 network. The LonWorks network connects to the
3-wire removable, keyed terminal block on the adapter.
The SHD connection (Figure 7) on the LonWorks network
terminal block is an isolated terminal and is not connected
in the network engine.
Wiring the Network Engine
Mount the network engine securely before you wire it. For
details, see Mounting.
CAUTION
Risk of Property Damage.
Do not apply power to the system before checking
all wiring connections. Short circuited or improperly
connected wires may result in permanent damage to
the equipment.
Attention
Risque de dégâts matériels.
Ne pas mettre le système sous tension avant
d'avoir vérifié tous les raccords de câblage. Des
fils formant un court-circuit ou connectés de façon
incorrecte risquent d'endommager irrémédiablement
l'équipement.
WARNING
Risk of Electric Shock.
Disconnect or isolate all power supplies before
making electrical connections. More than one
disconnection or isolation may be required to
completely de-energize equipment. Contact with
components carrying hazardous voltage can cause
electric shock and may result in severe personal injury
or death.
WARNING
Risque de décharge électrique.
Débrancher ou isoler toute alimentation avant
de réaliser un branchement électrique. Plusieurs
isolations et débranchements sont peut-être
nécessaires pour -couper entièrement l'alimentation
de l'équipement. Tout contact avec des composants
conducteurs de tensions dangereuses risque
d'entraîner une décharge électrique et de provoquer
des blessures graves, voire mortelles.
Important: Use this SNE only as an operating
control. Where failure or malfunction of the SNE
could lead to personal injury or property damage
to the controlled equipment or other property,
additional precautions must be designed into the
control system. Incorporate and maintain other
devices, such as supervisory or alarm systems or
safety or limit controls, intended to warn of or
protect against failure or malfunction of the SNE.
SNE Installation Guide 5
