JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
1 2
3 4
5 6
7
U - Upflow
0
D - Downflow for FlexSys
W - Water Cooled
A - Air Cooled
C - Chilled Water Cooled
S - Self-contained
Y - York
3
9
Nominal TonnageBase Product Type
BASE MODEL NUMBER
YSWU039 - YORK Versacon Water Cooled, Upflow, 39 Nominal Tons
YSWU - YORK Floor X Floor, Water Cooled, Upflow
YSAU - YORK Floor X Floor, Air Cooled, Upflow
YSCU - YORK Floor X Floor, Chilled Water Cooled, Upflow
YSWD - YORK Floor X Floor, Water Cooled, Downflow
YSAD - YORK Floor X Floor, Air Cooled, Downflow
YSCD - YORK Floor X Floor, Chilled Water, Downflow
ABOUT THIS MANUAL
This manual applies to Versecon Models YSWD/
YSWU012 to YSWD/YSWU090. This manual pro-
vides specific instructions for installation, owner main-
tenances, and troubleshooting.
Due to the dedication of continuous product improve-
ment and enhancements, the information provided is
subject to change without notice
DESCRIPTION OF UNIT
Versecon, the indoor vertical self-contained air con-
ditioner is the ultimate solution addressing the energy
efficiency, reliability, indoor air quality, and sound
concerns for commercial, industrial and institutional
buildings. Versecon offers a simple system design,
increases system redundancy by providing individual
air conditioning systems per floor, lowers maintenance
costs, eases operation and maintenance and provides the
lowest life cycle cost available. Based on these features,
the self-contained unit has surpassed the traditional
chillers, air handlers and rooftop systems and is now
the system of choice.
Models YSWD/YSWU012 to YSWD/YSWU090 are
factory assembled, refrigerant charged and tested, wa-
ter-cooled packaged air conditioning units designed for
ducted applications.
Each unit contains multiple hermetic scroll compres-
sors, water cooled condensers, multi-circuit evaporator,
thermal expansion valves, interconnecting refrigerant
piping, plenum supply fan, belt drive, fan motor, pleated
filters and all necessary operating and required safety
controls to operate the unit.
All rigging, installation, power and control wiring ex-
ternal to the unit, and condenser water and condensate
piping are the responsibility of the installer.
NOMENCLATURE
TABLE 1 – ACRONYM CHART
ACRONYM TEXT
AO Analog Output
AFS Air Flow Switch
DHS Duct High Static Switch
DSP Duct High Pressure Sensor
DO Digital Output
IN Universal Input
LCD Logic Controller Display
MSF Supply Fan Relay
OLSF Supply Fan Overload
PM Phase Monitor
PWS Power Supply
RSF Supply Fan Relay
S Toggle Switch
T Transformer
VFD Variable Frequency Drive
SAT Supply Air Temp
MAT Mixed Air Temp
AFS Air Flow Switch
DHS Duct High Static
RAT Return Air Temp
1
SECTION 1 – INTRODUCTION
