JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
DATA 012 016 021 025 032 039 048
Capacity
Range
Min. capacity (tons) 10 15 20 25 30 35 40
Max. capacity (tons) 20 25 30 35 45 55 65
Airflow
Range
Min. VAV design CFM 3,300 4,400 5,600 6,700 8,700 10,700 12,700
Max.VAV design & operating CFM 5,000 6,700 8,400 10,000 13,000 16,000 19,000
Cabinet
Dimensions
Depth (excluding return section) 70 70 70 70 70 70 70
Length 52 52 52 52 64 76 88
Height (excluding discharge plenum) 79 79 79 79 79 79 79
Box type M1 M1 M1 M1 M2 M3 M4
EER
Based on ARI 340/360-93 15.7 15.7 14.5 13.9 13.8 14.2 13.6
Cooling Coil
Section
Face Area 8.3 11.1 13.9 16.7 21.7 26.7 31.7
Rows–12 FPI* 4 or 6 4 or 6 4 or 6 4 or 6 4 or 6 4 or 6 4 or 6
Waterside
Econo
Section
Face Area 8.3 11.1 13.9 16.7 21.7 26.7 31.7
Rows–12 FPI 2 or 4 2 or 4 2 or 4 2 or 4 2or 4 2 or 4 2 or 4
Heating
Section
Hot Water Heat–Face Area 8.3 11.1 13.9 16.7 21.7 26.7 31.7
Rows–10 FPI 1 or 2 1 or 2 1 or 2 1 or 2 1 or 2 1 or 2 1 or 2
Electric Heat–kW TBD TBD TBD TBD TBD TBD TBD
Steam–Face Area 8.3 11.1 13.9 16.7 21.7 26.7 31.7
Rows–8 FPI 1 1 1 1 1 1 1
Return Air
Section
Filter Type 2” or 4” PLEATED, 12” CARTRIDGE
Filter Area (ft
2
) 18.3 18.3 18.3 18.3 24.4 28.5 32.5
20 x 20 Filter Quantity 3 3 3 3 9 3 12
20 x 25 Filter Quantity 3 3 3 3 - 6 -
Pre-Filter 2” or 4 2” or 4 2” or 4 2” or 4 2” or 4 2” or 4 2” or 4
Efficiency (%) 30 to 95 30 to 95 30 to 95 30 to 95 30 to 95 30 to 95 30 to 95
Final-Filter 4” or 12” 4” or 12” 4” or 12” 4” or 12” 4” or 12” 4” or 12” 4” or 12”
Efficiency (%) 65–95 65–95 65–95 65–95 65–95 65–95 65–95
Fan Section
Type AIRFOIL PLENUM FAN (SWSI)
Quantity–Dia. (in): standard capacity 1–18 1–18 1–18 1–18 1–20 1–24 1–24
Quantity–Dia. (in): high capacity 1–20 1–20 1–20 1–20 1–24 1–27 1–27
Motor HP range 1.0–20.0 1.0–20.0 1.0–20.0 1.0–20.0 1.5–20.0 2.0–20.0 2.0–20.0
Compressor
Section
Type SCROLL
Quantity 2 2 2 2 2 4 4
Stages–VAV systems 3 3 3 3 3 4–6 4–6
TABLE 6 – DATA TABLE
Due to �
* Aluminum fins standard. ** M-Available Modular Construction, N- for New Construction.
Continued on next page
PHYSICAL & ELECTRICAL DATA
