70
JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
Continued on next page
Device Object Instance (DE)
The unit is shipped to automatically establish the DE
address after the MAC address is established using the
rotary switches on the control. The default DE address
is 2300 plus the MAC address. Before setting the DE
address power must be removed from the control board.
The control only reads the address when the control
is turned on. The control has two rotary switches for
setting the MAC address (see Figure B). The switches
are identified on the control board as “Module Address”.
The switch on the left corresponds to the tens digit and
the switch on the right corresponds to the one digit.
For example, if you wanted a MAC address of 13 you
would set the left hand switch to 1 and the left hand
switch to 3.
Table 18 has the BACnet MS/TP points
TABLE 18 – BACnet MS/TP points
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
AcCltMod
Cooling Minimum Dew Point
Correction PID Output
BAV R 0 – 100 % 16127
Only with FlexSys
with Dew Point
Control
AcRat Enable
Cooling Return Air Temp Control:
1 = Active
0 = Inactive
BBV R/W - - 15003
AcRatMod
Return Air Temperature
Cooling PID Output
BAV R 0 – 100 % 16117
AcSad Enable
Cooling Dew Point Temp Control:
1 = Active
0 = Inactive
BBV R/W - - 15004
Only with FlexSys
with Dew Point
Control
AcSadMod Dew Point Cooling PID Output BAV R 0 – 100 % 16126
Only with FlexSys
with Dew Point
Control
AcSat Enable
Cooling Supply Air Temp Control:
1 = Active
0 = Inactive
BBV R/W - - 15002
AcSatMod
Supply Air Temperature
Cooling PID Output
BAV R 0 – 100 % 16116
Air Flow Swch
Air Flow Switch Status:
1 = Closed
0 = Open
BBI R - - 12004
Alarm Out
This is the Status of the Alarm
Out Output:
1 = Alarm – Active
0 = No Alarm – Inactive
BBO R/W - - 11010
Alarm Reset
Alarm Reset:
1 = Reset – Active
0 = Off – Inactive
BBV R/W - - 15200
B/P Max BAV 16016 Not Applicable
B/P Mod BAO 14003 Not Applicable
B/P Mod
The Actual Analog Output to
the Bypass Damper in %
BAO R/W 14003
Only on FlexSys
Units
User Interface Control Center
