TABLE 5 – WEIGHTS
UNIT WEIGHTS 012 016 021 025 032 039 048 050 055 060 072 079 090
COOLING COIL SECTION
CABINET 451 456 461 466 529 593 656 818 720 823 911 1135 1140
EVAPORATIVE COIL 168 206 244 282 350 418 486 528 554 592 694 761 855
WATERSIDE ECONOMIZER SECTION
4 ROW, 12 FPI 267 305 343 381 457 549 627 679 705 743 855 932 1,026
WATER WEIGHT 35 47 58 70 91 112 133 147 154 168 201 221 252
HEATING SECTION
HOT WATER HEAT 63 83 105 126 163 201 238 263 276 301 359 395 451
WATER WEIGHT 11 14 18 22 28 35 41 46 48 52 62 68 78
STEAM 63 83 105 126 163 201 238 263 276 301 359 395 451
ELECTRIC HEAT 21 21 21 21 21 21 42 42 42 42 42 42 42
RETURN AIR SECTION
FILTERS – 4" 30% 182 182 182 182 213 244 276 352 306 352 401 477 477
FAN SECTION
CABINET 451 456 461 466 529 593 656 818 720 823 911 1135 1140
FAN AND BASE
18" 203 203 203 203 - - - - - - - - -
20" 213 213 213 213 213 - - - - - - - -
22" - - - - 233 233 - - - - -
24" - - - - - 285 285 - - - - - -
27" - - - - - 428 428 - 428 - - - -
30" - - - - - - - 472 - 472 - - -
33" - - - - - - - 598 - 598 598 - -
36" - - - - - - - - - - 685 685 685
40" - - - - - - - - - - - 920 920
44" - - - - - - - - - - - - -
MOTOR HP
2 64 - - - - - - - - - - - -
3 100 100 - - - - - - - - - - -
5 117 117 117 117 - - - - - - - - -
7.5 194 194 194 194 194 194 - 194 - - - - -
10 213 213 213 213 213 213 213 213 213 213 213 213 -
15 - - 326 326 326 326 326 326 326 326 326 326 326
20 - - - - 368 368 368 368 368 368 368 368 368
25 - - - - - - 495 495 495 495 495 495 495
30 - - - - - - - - - 519 519 519 519
40 - - - - - - - - - - 602 602 602
50 - - - - - - - - - - - - -
VARIABLE FREQUENCY DRIVE
2 5 - - - - - - - - - - - -
3 8 8 - - - - - - - - - - -
5 13 13 13 13 - - - - - - - - -
7.5 51 51 51 51 51 51 - 51 - - - - -
10 51 51 51 51 51 51 51 51 51 51 51 51 -
15 - - 66 66 66 66 66 66 66 66 66 66 66
20 - - - - 66 66 66 66 66 66 66 66 66
25 - - - - - - 106 106 106 106 106 106 106
30 - - - - - - - - - 106 106 106 106
40 - - - - - - - - - - 106 106 106
50 - - - - - - - - - - - - -
