18
JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
REMOVE SHIPPING RESTRAINTS
Mechanical restraints are used to secure the spring
mounted supply fan during shipment (see Figure 2).
Restraints and shipping blocks must
be removed after unit has been set in
its final location.
TIE DOWN BOLTS
TYP FOUR PLACES
SUPPLY FAN ASSEMBLY
DETAIL A
SCALE 1:4
A
FIG. 2 – SHIPPING RESTRAINT LOCATIONS
LD12274
Installation
