TABLE 7 – REFRIGERANT CHARGE DATA

Continued on next page

MODEL #

# EVAP

COIL

ROWS

COMP A COMP B COMP C COMP D

NOM HP

R22

CHARGE

LBS

NOM HP

R22

CHARGE

LBS

NOM HP

R22

CHARGE

LBS

NOM HP

R22

CHARGE

LBS

DVW012 4 7 8 4 7.5 - - - -

DVW012 6 7 9.5 4 9 - - - -

DVW012 4 10 9.5 4 7.5 - - - -

DVW012 6 10 11 4 9 - - - -

DVW012 4 10 9.5 7 8.5 - - - -

DVW012 6 10 11 7 9.5 - - - -

DVW012 4 12 10 7 8.5 - - - -

DVW012 6 12 11.5 7 9.5 - - - -

DVW016 4 7 9 4 8.5 - - - -

DVW016 6 7 10.5 4 10 - - - -

DVW016 4 10 10 4 8 - - - -

DVW016 6 10 12 4 10 - - - -

DVW016 4 10 10.5 7 9 - - - -

DVW016 6 10 12 7 11 - - - -

DVW016 4 12 11 7 9 - - - -

DVW016 6 12 13 7 11 - - - -

DVW016 4 15 12 7 9 - - - -

DVW016 6 15 14 7 11 - - - -

DVW016 6 15 14 10 12.5 - - - -

DVW021 4 7 9.5 4 9.5 - - - -

DVW021 4 10 11.5 4 9.5 - - - -

DVW021 6 10 13.5 4 11.5 - - - -

DVW021 4 10 11.5 7 10 - - - -

DVW021 6 10 13.5 7 12 - - - -

DVW021 4 12 14 7 12 - - - -

DVW021 6 12 14 7 12 - - - -

DVW021 4 15 12 7 10 - - - -

DVW021 6 15 14 7 12 - - - -

DVW021 4 15 13 10 11.5 - - - -

DVW021 6 15 15.5 10 14 - - - -

DVW021 4 15 13 12 12 - - - -

DVW021 4 20 15.5 12 12 - - - -

DVW021 6 20 20 12 12 - - - -

DVW021 6 25 19 12 14.5 - - - -

DVW025 4 10 10 4 4 - - - -

DVW025 6 10 15 4 13 - - - -

DVW025 4 10 12 7 11 - - - -

DVW025 6 10 15 7 13.5 - - - -

DVW025 4 12 13 7 11 - - - -

DVW025 6 12 15.5 7 13.5 - - - -

DVW025 4 15 14 7 11 - - - -

DVW025 6 15 16.5 7 13.5 - - - -

DVW025 4 15 14 10 12.5 - - - -

DVW025 6 15 16.5 10 15 - - - -
