Johnson Controls York VERSECON YSWD Series User Manual

24
JOHNSON CONTROLS
FORM 145.05-NOM1 (708)
TABLE 7 – REFRIGERANT CHARGE DATA (CONT.)
MODEL #
# EVAP
COIL
ROWS
COMP A COMP B COMP C COMP D
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
NOM HP
R22
CHARGE
LBS
DVW025 4 15 14 12 13 - - - -
DVW025 6 15 16.5 12 15.5 - - - -
DVW025 4 20 16.5 12 13 - - - -
DVW025 6 20 19 12 15.5 - - - -
DVW025 6 25 20.5 12 15.5 - - - -
DVW025 6 25 20.5 15 17 - - - -
DVW032 4 7 4 - - - -
DVW032 4 10 14 4 12 - - - -
DVW032 4 10 14 7 12.5 - - - -
DVW032 4 12 14.5 7 12.5 - - - -
DVW032 6 12 18 7 16 - - - -
DVW032 4 15 15.5 7 12.5 - - - -
DVW032 6 15 19 7 16 - - - -
DVW032 4 15 15.5 10 14 - - - -
DVW032 6 15 19 10 17.5 - - - -
DVW032 4 15 15.5 12 15 - - - -
DVW032 6 15 19 12 18 - - - -
DVW032 4 20 18 12 15 - - - -
DVW032 6 20 21.5 12 18 - - - -
DVW032 6 25 23 12 18 - - - -
DVW032 6 25 23 15 19.5 - - - -
DVW039 4 4 9.5 4 9.5 4 9 4 9.5
DVW039 6 4 11.5 4 12 4 11 4 11.5
DVW039 4 7 10.5 4 9.5 7 10 4 9.5
DVW039 6 7 12.5 4 12 7 12 4 11.5
DVW039 4 7 10.5 7 11 7 10 7 10.5
DVW039 6 7 10.5 7 15 7 10 7 14.5
DVW039 4 10 12 7 11 10 11.5 7 10.5
DVW039 6 10 12 7 15 10 11.5 7 14.5
DVW039 4 12 13 7 11 12 12.5 7 10.5
DVW039 6 12 15 7 13 12 14.5 7 12.5
DVW039 4 10 14 10 14.5 10 13.5 10 14
DVW039 6 10 12 10 16.5 10 11.5 10 16
DVW039 4 12 13 10 12.5 12 12.5 10 12
DVW039 6 12 15 10 14.5 12 14.5 10 14
DVW039 4 15 14 7 11 15 13.5 7 10.5
DVW039 6 15 16 7 13 15 16 7 12.5
DVW039 4 12 13 12 13.5 12 12.5 12 13
DVW039 4 15 14 10 12.5 15 13.5 10 12
DVW039 6 15 16 10 14.5 15 16 10 14
DVW039 4 15 14 12 13.5 15 13.5 12 13
DVW039 6 15 16 12 15.5 15 16 12 15
DVW048 4 7 11.5 7 11.5 7 11 7 11
DVW048 6 7 11.5 7 16.5 7 11 7 16
Continued on next page
Installation
