TABLE 5 – WEIGHTS (CONT.)
UNIT
WEIGHTS
WATER
WEIGHT
012 016 021 025 032 039 048 050 055 060 072 079 090
COMPRESSOR/CONDENSER
(1) 4 & (1) 7 26 333 333 - - - - - - - - - - -
(1) 4 & (1) 10 34 358 358 - - - - - - - - - - -
(1) 7 & (1) 10 41 434 434 434 - - - - - - - - - -
(1) 7 & (1) 12 46 456 456 456 - - - - - - - - - -
(1) 7 & (1) 15 53 - 597 597 597 - - - - - - - - -
(1) 10 & (1) 15 60 - - 673 673 673 - - - - - - - -
(1) 12 & (1) 15 65 - - 694 694 694 - - - - - - - -
(1) 12 & (1) 20 77 - - - 856 856 - - - - - - - -
(1) 12 & (1) 25 89 - - - 905 905 - - - - - - - -
(1) 15 & (1) 25 96 - - - - 1,046 - - - - - - - -
(2) 7 & (2) 10 82 - - - - - 954 - - - - - - -
(2) 7 & (2) 12 91 - - - - - 1,016 1,016 - - - - - -
(4) 10 96 - - - - - 1,144 1,144 - - - - - -
(2) 7 & (2) 15 106 - - - - - 1,311 1,311 1,311 - - - - -
(4) 12 115 - - - - - 1,232 1,232 1,232 1,229 - - - -
(2) 10 & (2) 15 120 - - - - - - 1,483 1,483 1,490 1,483 - - -
(2) 12 & (2) 15 130 - - - - - - - 1,527 1,534 1,527 - - -
(4) 15 144 - - - - - - - 1,822 1,839 1,822 1,839 - -
(2) 12 & (2) 20 154 - - - - - - - - - 1,899 1,968 - -
(2) 15 & (2) 20 168 - - - - - - - - - 2,194 2,273 2,273 -
(2) 12 & (2) 25 178 - - - - - - - - - - 2,111 2,111 2,111
(2) 15 & (2) 25 192 - - - - - - - - - - 2,417 2,417 2,417
(2) 20 & (2) 25 216 - - - - - - - - - - - 2,851 2,851
(4) 25 240 - - - - - - - - - - - 2,994 2,994
(2) 25 & (4) 15 264 - - - - - - - - - - - - -
(6) 20 288 - - - - - - - - - - - - -
(2) 25 & (4) 20 312 - - - - - - - - - - - - -
(2) 20 & (4) 25 336 - - - - - - - - - - - - -
(6) 25 360 - - - - - - - - - - - - -
DISCHARGE PLENUM
FACTORY INSTALLED 492 492 492 492 560 627 695 759 763 759 846 1,073 1,073
Determine the approximate center of gravity for lifting
safety before lifting the unit.
Always test-lift the unit to determine the exact unit
balance and stability before hoisting it to the installation
location.
Units are provided with lifting lugs for rigging with a
crane. If the units are lifted by crane, protection against
chaffing damage by slings or cable must be provided,
and spreader bars must be used across the top of the
cabinet to prevent any structural damage to the frame.
