TABLE 18 – BACnet MS/TP points (CONT.)
Point ID Point Description
Variable
Type
Read ( R )
Write ( W )
Value
Range
(Analog
Only)
Unit
(Analog
Only)
Instance
Number
Comments
STOP MIN4 Stop Minutes for Schedule 4 BAV R/W 1 – 60 - 906
STOP MIN5 Stop Minutes for Schedule 5 BAV R/W 1 – 60 - 917
STOP MIN6 Stop Minutes for Schedule 6 BAV R/W 1 – 60 - 928
STOP MIN7 Stop Minutes for Schedule 7 BAV R/W 1 – 60 - 939
STOP MIN8 Stop Minutes for Schedule 8 BAV R/W 1 – 60 - 950
STOP MIN9 Stop Minutes for Schedule 9 BAV R/W 1 – 60 - 962
StType
1 = High
2 = Avg
3 = Low
Type of Duct Static Pressure
Control with Two Duct Static
Pressure Inputs
BAV R/W - - 16015
Suct P Min* BAL - - 16008 Not Applicable
SUNDAYSCHED1
Turns Sunday On / Off for
Schedule 1:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 880
SUNDAYSCHED10
Turns Sunday On / Off for
Schedule 10:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 980
SUNDAYSCHED11
Turns Sunday On / Off for
Schedule 11:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 991
SUNDAYSCHED12
Turns Sunday On / Off for
Schedule 12:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1002
SUNDAYSCHED13
Turns Sunday On / Off for
Schedule 13:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1013
SUNDAYSCHED14
Turns Sunday On / Off for
Schedule 14:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1024
SUNDAYSCHED15
Turns Sunday On / Off for
Schedule 15:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1034
SUNDAYSCHED16
Turns Sunday On / Off for
Schedule 16:
1 = On – Active
0 = Off – Inactive
BBV R/W - - 1045
