MAINTENANCE
FUEL SYSTEM
3
FUEL SYSTEM
Breather and Fuel Line
If leakage, cracks, swelling, or other damage is
found, replace the breather and/or the fuel line.
Fuel Filter
If water accumulation, sediment, leakage, cracks,
or other damage is found, replace the fuel filter.
Carburetor
If damage is found, replace the carburetor.
LUBRICATION
Engine Oil
Refer to INSPECTION AND MAINTENANCE
SCHEDULE on p. 38 for oil change schedule.
IMPORTANT: Engine oil should be changed
while engine is warm.
Place outboard upright on a level surface.
Remove the oil filler cap.
Place a container under engine oil drain plug
(underside of lower engine cover), then remove
plug and gasket to drain engine oil.
Install new gasket and oil drain plug. Tighten plug
to 7 ft. lbs. (10 N·m).
IMPORTANT: Do not re-use gasket once
removed. Always use a new gasket.
005886
005887
005945
1. Oil filler cap 005888
1. Oil drain plug 005889
1
1
