11
SX600 MANUAL • INTRODUCTION 5: Trainer System
The SX600 features a built-in trainer system.
The transmitter can be used as either a master
(trainer) or as a slave (trainee). The SX600 is
compatible with all other current JR radios
that have built-in trainer systems. An optional
trainer cord (JRPA130) is needed .
1. Match the servo reversing, sub-trims, travel
adjust, and trims of both radios.
2. Plug the optional trainer cord into both
transmitters.
3. Turn on the master transmitter.
Note: The slave radio must be left off.
4. Test all the control functions on your aircraft
with the master radio.
5. Push the Trainer button on the master
transmitter and check all the control
functions with the slave radio.
INTRODUCTION 5: TRAINER SYSTEM
TRAINER SYSTEM
5
Operating the Trainer System
Master TX
Power Switch On
Slave TX
Power Switch Off
Optional
Trainer Cord
(JRPA130)
Trainer
Button
Trainer
Cord Input
To Next Page
