5
SX600 MANUAL Quick Start
SX600 QUICK START
Press the Scroll
button until
“TRV ADJ” appears
on the screen.
Press the Channel button to
select the channel on which
you want the travel adjusted.
INCREASE
To increase the travel, move
the stick (i.e. aileron) to the
right then press the Increase
button to adjust the right
travel. Release the Increase
button and move the same
stick to
the left. Press the Increase
button to adjust the left travel.
DECREASE
To decrease the travel, move
the stick (i.e. aileron) to the
right then press the Decrease
button to adjust the right
travel. Release the Decrease
button and move the same
stick to the left. Press the
Decrease button to adjust the
left travel.
A
B
C
TRAVEL ADJUSTMENT
3

Press the Scroll and Increase buttons upwards
simultaneously to return to the main screen and exit the
Function mode.
Note: Before flying, check that the direction and travel of all control
surfaces move correctly.
Before the initial start of your model, please
check to ensure that when the Throttle Cut
button is pressed, the engine’s carburetor
barrel will move to the fully closed (engine off)
position.
This safety feature ensures that the engine can
be shut off immediately in case of a problem or
safety concern.
THROTTLE AUTO CUT
4
A I L
+100
%
A I L
+107
%
A C i
10.4v
