SX600 MANUAL • INTRODUCTION 2: Features
INTRODUCTION 2: FEATURES CONTINUED
ST47 Servo
• An ultra-tight deadband amplifier ensures
accurate neutral centering
• Low current drain
• An indirect drive feedback potentiometer
gives additional protection from vibration
SERVO FEATURES
2.3
SERVO LAYOUT
2.4
Servo Eyelet
Servo Mounting Flange
Rubber Grommets
Top View
Rubber Grommets
Servo Case
Servo Lead w/Connector
Servo Output Shaft
Servo Mounting Flange
Servo Arm/Horn
Servo Arm Retaining Screw
