SX600 MANUAL • INTRODUCTION 3: Specifications
INTRODUCTION 3: SPECIFICATIONS
SYSTEM SPECIFICATIONS
TRANSMITTER SPECIFICATIONS
3.1
3.2
SYSTEM NAME SX600
TRANSMITTER BODY SX600
RECEIVER RS600
CHARGER NEC-221
AIRBORNE BATTERY JSPB700
SERVOS NES-ST47 x 4
ACCESSORIES Mini Switch
12" Aileron Extension
Servo Accessories
Instruction Manual
TYPE AIRPLANE
MODEL NUMBER SX600
ENCODER 6-CHANNEL COMPUTER SYSTEM
RF 72 MHZ
MODULATION PPM (FM)
OUTPUT POWER APPROXIMATELY 1 WATT
CURRENT DRAIN 200MA
POWER SOURCE 1.2V X 8 NICAD (9.6V) 600MAH
OUTPUT PULSE 1000-2000 (1500 NEUTRAL)
TYPE AIRPLANE
SERVO SPECIFICATIONS
3.3
TORQUE (OZ/IN) 47
SPEED (SEC/60°) .24
WEIGHT (OZ) 1.55
SIZE (IN) (W X L X H) 0.73 X 1.52 X 1.32
BB NO
MOTOR 3-POLE FERITE
TYPE ST47
