Section 22 Specifications 22-8
22.6 Trackball Operation Unit
GENERAL SPECIFICATION NCE-5605: Trackball Operation Unit
Pointing Device 2inch Trackball
Click Button 2-buttons (Left and Right)
USB I/F 1
Speaker 1
Keys SILENCE/ALERT ACK/ZOOM IN/ZOOM OUT
Knob Multi Function Knob
Cable Length Up to 5 m (Up to 30m when using the extended option)
Mechanical
Dimension Width 130 x Depth 210 x Height 77 (mm)
Mass 1.3kg
Environment
Operational Temperature -15ï‚°C to +55ï‚°C
Operational Humidity 40ï‚°C RH 93%
Vibration
Sweep 2 Hz to 13.2Hz at ± 1 mm, 13.2 Hz to 100 Hz at
7m/s2 and for 2h on each resonance, otherwise 2h at
30Hz in all three axes
EMC IEC60945-Ed4.0
Ingress Protection Rating Front : IP22
