22.7 19inch Display (NWZ-207)
GENERAL SPECIFICATION NWZ-207: Display
Screen Size 19inch
Aspect Ratio 5:4
Full Resolution 1280  1024
Supported format
1280  1024, 1280  960, 1024  768, 800  600, 640 
480, 720  400
Dot Pitch 0.294 mm
Viewing Area 376.32 mm  301.06 mm
Display Colors 16.77 million colors
Contrast Ratio 2000:1
Viewing Angles (H / V) 178°/178°
Back Light LED
Brightness 500cd/m
2
Type
Digital Scanning Frequency (H / V)
Horizon 30 kHz to 80 kHz
Vertical 56 Hz to 75 Hz
DVI-D input 1
VGA input 1
VGA output N/A
USB Flash Memory 1
Power 21.6 to 31.2VDC
Overvoltage Protection N/A
DC Reverse Connection Protection Self Return Type
Cables Up to 5m
Glass Bonding Standard
Mechanical
Dimension Width 429 x Depth 76 x Height 382 (mm)
Mass 6.0kg
Fan 1
Glass Tempered Glass + AR Coating
Environment
Operational Temperature -15°C to +55°C
Operational Humidity 40°C RH 93%
Vibration
Sweep 2 Hz to 13.2 Hz at ± 1 mm, 13.2 Hz to 100 Hz at 7
m/s
2
and for 2h on each resonance, otherwise 2h at 30 Hz
in all three axes
EMS IEC60945-Ed4.0
Ingress Protection Rating Front:IP65 Back:IP22
