JRC JLN-205MK2 User Manual

1-3
1.3.2 Options
1) MID/Doppler Log/GPS Navigator
No. Description Model No. CODE QTY Remarks
1
DATA POWER
CABLE
CFQ-5766D CFQ5766D 1 14 cores 10 m/ With Fuse holder
data, power, contact
CFQ-5766F CFQ5766F 1 14 cores 20 m/ With Fuse holder
data, power, contact
2
DATA CABLE CFQ-5767 CFQ5767 1 4 cores/3 m data
6-pin connector data line only
3
DATA CABLE CFQ-5768 CFQ5768 1 6 cores-14 cores/3 m daisy chain
4
DATA CABLE CFQ-5769 CFQ5769 1 For RS-485 4 cores/3 m
5
T-SHAPED
CONNECTOR
AA-040404-MMM-TL 5JCDX00071 1 For CFQ-5769 RS-485
6
JUNCTION BOX CQD-10 CQD-10C 1 16 terminals
7
L-TYPE ADAPTER CFQ-9184 CFQ9184 1
2) MID
No. Description Model No. CODE QTY Remarks
1
AC POWER
RECTIFIER
NBD-577C NBD-577C 1 AC100/220V input
24V output
2
DIMMER UNIT NCM-227 NCM-227 1 External dimmer unit
3
INSTRUCTION
MANUAL
7ZPNA4284 7ZPNA4284 1 English for MID
7ZPNA4283 7ZPNA4283 1 Japanese for MID
3) Doppler Log
No Description Model No. CODE QTY Remarks
1
SUB DISPLAY NWZ-4610 NWZ-4610 2Max
2
ANALOG DISPLAY
NWW-24 -
2Max.
Flush mount type
NWW-25 - Wall mount type
NWW-26 - Panel mount type
3
REMOTE DISPLAY
NWW-5 - 1Max. Fore/Aft. Speed &. Direction
NWW-16 -
Fore/Aft. Speed &. Direction
Distance
4
DISTANCE
COUNTER
NWW-7 - 1Max. Distance, 9999.99NM Max.
5
DIMMER UNIT
NCM-227 - -- for Main/Slave/Remote Display
NCM-329 - -- for Analog Display
6
TRANSDUCER NKF-531E - 1
Gate Valve type
With cable 25m
