5-6
Symptom Possible Causes Troubleshooting Measures
Data is not shared.
The baud rate is different. Check the RS-485 or Daisy-chain bit
rate. (Daisy-chain is only MID.)
Output sentence is not selected. Check the RS-485 output sentence.
The cable is disconnected. Check the RS-485 or Daisy-chain
connection. (Daisy-chain is only MID.)
5.3.2 Repair Unit
Repair units and their models are shown below.
No Name Model Notes
1 DSP UNIT CMJ-562
2 POWER UNIT CMP-490
3 LCD UNIT CCN-423
FUSE
No Name Model Notes
1 FUSE
MF60NR
250V 1
for Data power cable
1A FUSE
Mechanical Parts
No Name Code Notes
1 FRONT PANEL KIT MPBC47673
FRONT PANEL
PRODUCT NAMEPLATE
JLR-4341
No Name Code Notes
1 Beacon Antenna CAW-1 For JLR-4341 DGPS Sensor
2 Beacon Controller CMA-920 For JLR-4341 DGPS Sensor
5.3.3 Regular Replacement Parts
Parts which should be regularly replaced are shown below.
Contact JRC or an affiliate to order.
NWZ-4610
No Name Model Life Notes
1 LCD UNIT CCN-423 40000 hours
Approximately 5 years of
continuous use
JLR-4341
No Name Model Life Notes
1
Lithium Battery
(Inside JLR-4341
DGPS Sensor)
CR2354-1VC
Approximately
5 years
Reception is possible even without
battery power.
(It will take 30 to 60 seconds
longer to fix the position)
2
Radome Kit
(JLR-4341 DGPS
Sensor Radome
and Packing)
MPAE30534
Battery
replacement
Opening the radome decreases
waterproofing effectiveness, so
replace the radome and packing
as well as when performing battery
replacement.
To Next Page
