JMA-9100/7100 Installation Manual > 4.INITIAL SETTING > 4.9 MAIN BANG SUPPRESSION SETTING
4－15
4
• Rotate [GAIN] control to the maximum position (clockwise fully).
• Rotate the [SEA] control to achieve the strength with which main bang can be judged.
4) Adjust the value to eliminate the main bang.
[II] Main Bang Suppression Area Adjustment (MBS Area)
Procedures
1) Open the [Service Man Menu] screen.
2) Open the [2.MBS Area] screen according to the operation shown below.
3) Set the radar as shown below.
• Set the range to 0.125 nm.
• Set the radar video enhance function (ENH) at OFF.
• Set the correlation processing function (PROC) at OFF.
• Rotate [RAIN] control to the minimum position (counterclockwise fully).
• Rotate [GAIN] control to the maximum position (clockwise fully).
• Rotate the [SEA] control to achieve the strength with which main bang can be judged.
4) Adjust the value to eliminate the main bang.
9. RADAR/TT Initial Setup
→
3. MBS
→
2. MBS Area
To Next Page
