Page #44 background image
2-36
3) Installation and clamping method
a) Installation direction
Installation should be done so that the cable gland is oriented toward the
stern.
b) Bolts, unts and tightening torque to be used
Use stainless steel bolts for the scanner and uniformly tighten all of the bolts
using double nuts for each bolt so that the scanner will not become loose
(Table 2-3).
Although the length of the bolt will differ according to the thickness of the
mount base, use a bolt long enough so that more than 4 millimeters of
thread protrudes beyond the double nuts after the double nuts have been
tightened.
Table 2-3 Length of scanner mounting bolts and tightening torque
Thickness of Mount
Base(mm)
Bolt
Torque
(N-m)
S-band 19 M12×65(mm) SUS304 65
X-band 12 M10×55(mm) SUS304 40
