5-1
5. Setting
5.1 Port Setting
5.1.1 Display the Device Menu
1) Push the [POWER] button of the control unit and start up a display unit.
2) Move the cursor onto [Startup Menu], right-click the mouse and display [Password Dialog].
3) Input password [8510] and left-click the [OK] button. The [Device Menu] menu will appear.
※1：The serviceman menu can be mumbling when left-clicking the [Hide] button and usual [Startup Menu]
is displayed.
After the setting finished, left-click [Hide] button.
Startup Menu Password Dialog
Device Menu
※1
To Next Page
