Table 2-3 Swing circle
Scanner unit (length) Swing circle
NKE-1125-6 (6 feet) 1910mm
NKE-1129-7 (7 feet) 2270mm
NKE-1125-9 (9 feet)
NKE-1129-9 (9 feet)
2825mm
NKE-1130/1139 (12 feet） 4000mm
• Avoid having a rope or signal flag from winding around the radiating section
thereby preventing it from rotating.
• Avoid the effects of dust and heat caused by smoke from a chimney.
• When determining the appropriate scanner height and installation location,
take into consideration the reduction of vibration, the strength of the hull and
the scanner mount base, and maintenance properties.
• Provide for maintenance space: platform, safety link, hand rail, steps, etc.
