5-4
Confirmation the IP address
The IP address of the setting of an Ethernet uni-selector in the CQD-2121 standard terminal board and
the to that supporting NCM-860 control unit and the IP address which is set to Serial Relay I/F Board, the
Radar I/F board can be confirmed when clicking Confirm IP by the Configulation Set dialog.
※ plan to use the sub IP address when duplicating a LAN in future and at present, doesn't use it.
The setting of an Ethernet uni-selector in the
CQD-2121 standard terminal board.
The IP address of the
NCM-860 control unit
The IP address of Serial
Relay I/F Board1
The IP address of Serial
Relay I/F Board2
The IP address of Radar
I/F Board
To Next Page
