– 2 –
5) Fit knee lifter pressing rod
. Fit hinge
into the opening in the machine bed, and t the machine head
to table rubber hinge seat
before placing the machine head on cushions
on the four corners.
6)
Securely attach head support rod
to the table until it goes no further.
* Be sure to install the machine head support bar supplied with the unit.
7) Draw out cable
of the control box through cable draw-out hole
to route it to the underside of the sew-
ing machine table.
1) Carry the sewing machine while holding the
machine arm with two persons as shown in the
gure.
(Caution)
Never hold the handwheel since it rotates.
2) Place the sewing machine on a horizontal and
plane place when placing it and do not place any
protruding thing such as a screwdriver or the like.
3) Adjust so that the oil pan is supported at the four
corners of the table. Mount rubber hinge seat
on the table and x it on the table with a nail.
4) Fix two rubber seats
on side
A
(operator’s
side) using nails
as illustrated above. Fix two
cushion seats
on side
B
(hinged side) using a
rubber-based adhesive. Then place oli pan
on
the xed seats.
II. SET-UP
1. Installation
A
B
19.5mm23.5mm
To Next Page
