JUKI DDL-7000A-7 Series - Attaching the Connecting Rod

– 4 –
󰿿
󱀂
󱀁
󱀁
󱀀
Fix connecting rod
󰿿
to installing hole
󱀂
of pedal
lever
󱀀
with nut
󱀁
.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o󰀨 and a lapse of 5 minutes or more.
4. Attaching the connecting rod
