– 31 –
50
Pedal
specication
Type of pedal sensor is selected.
0
: KFL
1 : PFL
Refer to
“
#
-10. Selection of the pedal specications” p.43.
0/1
5 0
1
43
51 Compensation of
solenoid-on timing
of reverse feed
stitching at the
start of sewing
Compensation of starting the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
– 36 to 36
(10°)
5 1
1 2
39
52 Compensation of
solenoid-off timing
of reverse feed
stitching at the
start of sewing
Compensation of releasing the solenoid for reverse feed stitch-
ing when reverse feed stitching at the start of sewing is per-
formed.
– 36 to 36
(10°)
5 2
1 8
39
53 Compensation
of solenoid-off
timing of reverse
feed stitching at
the end of sewing
Compensation of releasing the solenoid for reverse feed stitch-
ing when reverse feed stitching at the end of sewing is per-
formed.
– 36 to 36
(10°)
5 3
1 6
39
55
Foot lift after
thread trimming
Function of lifting presser foot at the time of (after) thread trimming
0 : Not provided with the function of automatic lifting of work-
clamp after thread trimming
1 : Provided with the function of lifting presser foot
automatically
after thread trimming
0/1
5 5
1
40
56
Reverse
revolut
ion to lift
the needle after
thread trimming
Function of reverse revolution to lift the needle at the time of (af-
ter) thread trimming
0 : Not provided with the function of reverse revolution to lift
the needle after thread trimming
1 : Provided with the function of reverse revolution to lift the
needle after thread trimming
0/1
5 6
0
40
58
Function
of holding
predetermined
upper/lower
pos
ition of the
needle bar
Function of holding predetermined upper/lower position of the needle bar
0 : Not provided with the function of holding predetermined
upper/lower position of the needle bar
1 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is weak.)
2 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is medium.)
3 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is strong.)
0 to 3
5 8
0
40
59
Function of Auto/
Manual change-
over of reverse
feed st
itching at
the start of sewing
This function can specify the sewing speed of reverse feed
stitching at the start of sewing.
0 : The speed will depend on the manual operation by pedal, etc.
1 :
The speed will depend on the specied reverse feed stitching speed (No. 8).
0/1
5 9
1
40
60
Function of stop
immediately after
reverse feed
st
itching at the
start of sewing
Function at the time of completion of reverse feed stitching at
the start of sewing
0 : Not provided with the function of temporary stop of the
sewing machine at the time of completion of reverse feed
stitching at the start of sewing
1 : Provided with the function of temporary stop of the sew
-
ing machine at the time of completion of reverse feed
stitching at the start of sewing.
0/1
6 0
0
40
64
Change-
over speed of
condensat
ion
stitch or EBT (end
back tack)
Initial speed when starting condensation stitch or EBT
0 to 250
(sti/min)
6 4
1 8 0
70
Function of soft-
down of presser
foot
Presser foot is slowly lowered.
0 : Presser foot is rapidly lowered.
1 : Presser foot is slowly lowered.
0/1
7 0
0
41
71
Double reverse
feed stitching
function
Effective/ineffective of double reverse feed stitching is changed
over.
0 : Inef
fective
1 : Effective
0/1
7 1
1
72
Sewing
machine startup
selecting
function
Current limit at the startup of sewing machine is specied.
0 : Normal (Current limit is applied during startup)
1 : Rapid (Current limit is not applied during startup)
0/1
7 2
0
73
Retry function
This function is used when needle cannot pierce materials .
0 : Re-try function is not provided
1 - 10: Re-try function is provided
(Needle-bar returning force before re-trying: 1 (small) - 10 (large))
0/1
7 3
1
41
76
One-shot function
One-shot operation up to the material end is specied.
0 : One-shot operation is not performed.
1 : One-shot operation is performed.
0/1
7 6
0
33
*
84
Initial motion
suction time of
presser foot lifting
solenoid
Suction motion time of presser foot lifting solenoid
50 to 500
(ms)
8 4
2 5 0
41
No.
Item Description
Setting range
Indication of function setting
Ref. page
