3 Identifying the instrument
1
not with 2-wire output (405 or 453).
not with supply voltage 27.
2
for barometric pressure measurement
(if applicable, state site altitude a.m.s.l)
3
with housing 122 x 120 x 75 mm and automatic zeroing.
Not with 2-wire output (405 or 453).
416 0—10 V, square root
451 0—20 mA extended response time
452 0—20 mA, square root extended response time
453 0—20 mA 2-wire extended response time
454 4—20 mA extended response time
455 4—20 mA, square root extended response time
456 0—10 V extended response time
457 0—10 V, square root extended response time
(5) Supply
02 230 V -10% to +6% AC, 50—60 Hz
05 115 V -10% to +6% AC, 50—60 Hz
08 24 V -10% to +6% AC, 50—60 Hz
27 11.5—30 V DC (with 4—20 mA 2-wire output)
28 19—31 V DC
(6) Process connection
296 screwed pipe connection 8 mm
298 6.6 x 11 mm dia. (for flexible hoses 8 mm dia.)
(1) (2) (3) (4) (5) (6)
Order code 404304 /
Order example 404304 / 000 - 414 - 406 - 02 - 298
