10
4 Mounting
Fixing ✱ Use the lugs to fix the instrument.
The instrument should preferably be fixed vertically (pressure con-
nections below), since it has been factory-calibrated in this posi-
tion.
This ensures that no condensate from the pressure lines will enter
the measuring system.
Do not install the instrument close to sources of interference
(transformers, transmitters, motors) or heat sources.
Shock or vibration will lead to measurement errors.
