11
5 Installation
5.1 Electrical connection
Opening the
instrument
✱ Unscrew the four slotted screws
✱ Remove cover
When connecting the instrument, please observe the VDE regula-
tions concerning work with mains supply voltage, as well as the
regulations of the trade insurance associations regarding work on
and with electrical equipment and installations.
Never connect the supply voltage to the output terminals!
For the required supply voltage, see nameplate.
Instruments with DC supply have a reverse polarity protection.
