5 Program editor
5 Program editor
This menu is available on the device if the device has been configured as a program controller.
The default settings are shown in bold in the tables.
5.1 Program administration
Using the program editor, the user can create a program for a setpoint value and four operating contacts
with up to 24 program sections. The individual program sections and the respective setpoint value can
be programmed either on the device or in the setup program. The operating contacts can only be con-
figured using the setup program.
Settings that affect the program sequence (e.g. program start, setpoint value change as a step or ramp,
program repeat) are configured in the program controller configuration (accessible in the program editor
via the "Generator configuration" button).
Parameter Selection/text/value Description
Program name
(setup only)
<Enter text>
Program 01
Free choice of name for the program
Generator configuration
(setup only)
Press button Use this button to open a menu for configuring the
program controller.
Cut
(setup only)
Press button Use this button to cut lines (program sections) that
have been marked.
Copy
(setup only)
Press button Use this button to copy lines that have been
marked.
Insert
(setup only)
Press button Use this button to insert lines that have been cut or
copied above a selected line.
New
(setup only)
Press button Use this button to insert a new line above a marked
line.
Remove
(setup only)
Press button Use this button to delete lines that have been
marked.
No. (number)
(setup only)
Select section to be pro-
grammed (starting with
section 1)
Number of program section (for program creation
with the setup program)
Section 1 to
section 24
(device only)
Select section to be pro-
grammed (starting with
section 1)
Number of program section (for program creation
on the device)
Setpoint value 1 -1999 to 9999
(0 to 400)
Setpoint value in corresponding program section
The input limits depend on the controller configura-
tion (setpoint value 1: min. limit, max. limit).
Duration Duration of program section
Setting range and unit depend on the program
controller configuration ("Time display" parame-
ter):
00:00 to 59:59 mm:ss
00:00 to 23:59 hh:mm
00:00 to 99:23 dd:hh
