8 Configuration - setup only
78
ST editor
Press the corresponding button to start the ST editor.
NOTE!
There is a separate manual for the ST editor available with further information.
8.2 Digital control signals
The device provides the option to individually configure up to four digital control signals. The following
configuration parameters are available for each of the four control signals.
Decimal places Number of pre-decimal and decimal places for the
numerical display of the value
Auto Automatic
XXXX. No decimal place
XXX.X One decimal place
XX.XX Two decimal places
X.XXX Three decimal places
Parameter Selection/text/value Description
Parameter Selection/text/value Description
Digital signal Digital selector
No selection
Input signal (or OR/AND/XOR signal 1)
Function Without function The output signal corresponds to the input signal
(with inverting if necessary).
Impulse A pulse-like signal is output as long as the input
signal is active (high).
Delay The output signal follows the course of the input
signal, whereby the transfer from low to high status
and vice versa is delayed.
Pulse function The output signal is activated for the duration of
the pulse time for the rising edge of the input sig-
nal.
Rising edge The output signal is activated for the duration of a
cycle interval for the rising edge of the input signal.
Falling edge The output signal is activated for the duration of a
cycle interval for the falling edge of the input signal.
OR function Logical OR link of the input signals (signal 1,
signal 2, signal 3)
AND function Logical AND link
XOR function Logical XOR link
Signal 2 Digital selector
No selection
Second input signal for the logical link
Signal 3 Digital selector
No selection
Third input signal for the logical link
Inversion No Output signal (control signal) not inverted
Yes Output signal (control signal) inverted
