7 Configuration
Timer signals
Timer output: The signal is active from the start until the timer elapses (high active or low active configu-
rable).
Tolerance band signal timer: The signal is active if the actual value before the timer start is outside the
valid range. If the actual value after the timer starts runs out of the valid range, the timer time is only
stopped (timer stop signal active) until the actual values reaches the valid range again! The tolerance
band signal is not active in this case.
End signal timer: The signal is active after the timer elapses for the duration of the after-run time (or
until acknowledgement).
Stop signal timer: The signal is active while the timer is stopped.
Timer symbol (display)
Off: Timer is not active (function = off)
Lights up: Timer is active (function = on)
Flashes: Timer is active and running (symbol also flashes during lead time, if timer has stopped, and
during after-run time)
Behavior after power on
The timer output signals are inactive during the device's initialization phase. The runtime and remaining
running time are saved via power off on the device. The behavior after power on is configurable.
7.12 Limit value monitoring functions
The device is equipped with four limit value monitoring functions that can be individually configured. The
following configuration parameters are available for each of the four limit value monitoring functions.
Tolerance band 0 to 9999 Standard tolerance band (in Kelvin) around the
setpoint value
After the timer is started, the timer time only runs
from the point in time when the actual value reach-
es the tolerance band.
0 = Start without tolerance band
Tolerance band actual
value
Analog selector
No selection
Actual value for tolerance band function
Tolerance band setpoint
value
Analog selector
No selection
Setpoint value for tolerance band function
Additional functions
(setup only)
Expansion 1 Reserved function for service purposes. Only acti-
vate when instructed to do so by service person-
nel!
Click checkbox to activate the function.
