7 Configuration
48
7.3 System data
The general system data is configured in this menu.
7.4 Display/operation
Settings are implemented in this menu that affect the function of the displays and the device buttons.
Flags Digital flags 1
digital flags 2
Digital flags are binary values that can be de-
scribed and read out as well as internally pro-
cessed via the interface.
Logic Logic result 1 to
logic result 4
Results of the logic formulae (formula 1 to formula
4)
ST digital outputs ST digital output 1 to
ST digital output 4
Signals of the digital outputs from the PLC module
(application created with ST code)
ST alarm/error ST alarm Alarm signal from the PLC module (application
created with ST code)
ST error Error signal from the PLC module (application cre-
ated with ST code)
Service Service signal The signal is activated if the service counter has
reached the set limit value and remains active until
acknowledgement.
Operation Short-press back button
(< 2 s)
The signal is active (for the duration of a sampling
period) after briefly pressing the "Back" button.
Long-press back button
(> 2 s)
The signal is active (for the duration of a sampling
period) after long-pressing the "Back" button.
Category Signal Description
Parameter Selection/text/value Description
Device name
(setup only)
Name
(editable)
Device designation (in the "Device information"
menu)
National language German
English
French
Spanish
National language of display texts
Language selection ac-
tive
No
Yes
Language selection after switching on the next
time
If "Yes", the user can select the national language
for the device texts after the next time the device is
switched on - following the change to the configu-
ration.
After applying the national language, this parame-
ter is automatically set to "No", so that language
selection is not necessary the next time the device
is switched on.
Temperature unit °C
°F
Temperature unit for the display on the device and
in the setup program (automatic conversion from
°C to °F)
Temp. unit interface °C
°F
Temperature unit for temperature values trans-
ferred via the serial interface.
