47
7 Configuration
Digital selector
Service Terminal temperature Temperature on the connection terminals
Service counter Service counter reading (number or time, configu-
ration dependent)
Operating time Operating hours counter reading (in hours or days,
configuration dependent)
Category Signal Description
Category Signal Description
No selection No signal selected
Digital inputs Digital input 1
digital input 2
Signals of digital inputs 1 and 2
Controller Controller off The signal corresponds to the controller-off signal
(switch off controller).
Autotuning The signal is active during autotuning.
Manual mode active The signal is active during manual mode.
Controller cycle alarm Control loop monitoring alarm signal
Output level alarm Output level monitoring alarm signal
Controller output 1 (digi-
tal)
Signal on controller output 1 (e.g., for heating with
inverse control direction)
Controller output 2 (digi-
tal)
Signal on controller output 2 (e.g., for cooling with
inverse control direction)
Program Program active The signal is active while the program is running
(also while the program is stopped).
Program tolerance band
signal
The signal is active while the actual value is out-
side the tolerance band.
Operating contacts Operating contact 1 to
operating contact 4
Operating contacts of the program generator
Ramp End signal ramp The signal is active after ramp end until the next
setpoint value change.
Ramp tolerance band
signal
The signal is active while the actual value is out-
side the tolerance band.
Limit value monitoring
functions
Limit value monitoring
function 1 to
limit value monitoring
function 4
Alarm signals of limit value monitoring functions 1
to 4
Timer Timer output The signal is active from timer start until the timer
elapses (high active or low active configurable).
Timer tolerance band
signal
The signal is active if the actual value before the
timer start is outside the tolerance band.
Timer end signal The signal is active after the timer elapses for the
duration of the after-run time (or until acknowl-
edgement).
Timer stop signal The signal is active while the timer is stopped.
Digital control signals Digital control signal 1 to
digital control signal 4
Output signals of the respective function (confi-
gurable)
Ext. digital inputs Ext. digital input 1
ext. digital input 2
Signal of the external digital inputs 1 and 2 (via in-
terface)
