7 Configuration
58
Controller type
Description of the controller types:
chapter 6.2 "Controller types", page 43
Behavior after power on
The controller outputs are inactive during the initialization phase (output level 0 %, relay in standby
mode).
7.9.2 Controller input
The controller input signals are assigned in this menu.
Control direction Direct The controller output level is positive if the actual
value is greater than the setpoint value (cooling).
Inverse The controller output level is positive if the actual
value is smaller than the setpoint value (heating).
Manual mode
(setup only)
Enabled Changeover to manual mode possible (through
button operation or digital signal)
Inhibited Changeover to manual mode is inhibited.
Y in manual mode Output level after changeover to manual mode
Current value Current output level before changeover
Y manual mode Configurable value (see "Y manual mode" param-
eter)
Y manual mode -100 to +100 (0) Output level (in percent) in manual mode
Y with error Output level in the event of a fault (outside of the
measuring range)
Current value Current output level before fault occurs
Y replacement value Configurable value (see "Y replacement value" pa-
rameter)
Y replacement value -100 to +100 (0) Output level (in percent) in the event of a fault
Additional functions
(setup only)
Parameter 1 to
parameter 4
Reserved function for service purposes. Only acti-
vate when instructed to do so by service person-
nel!
Click checkbox to activate the function.
Parameter Selection/text/value Description
Parameter Selection/text/value Description
Controller actual value Analog selector
Analog input
Analog signal as actual value of the controller
Controller setpoint value Analog selector
Current setpoint value
Analog signal as controller setpoint value
Signal 1 setpoint
changeover
Digital selector
No selection
Signal (bit 0) for controlling setpoint changeover
Signal 2 setpoint
changeover
Digital selector
No selection
Signal (bit 1) for controlling setpoint changeover
Manual/auto change-
over signal
Digital selector
No selection
Signal (high-active) for changeover to manual
mode
Manual mode signal in-
hibition
Digital selector
No selection
Signal (high active) for inhibiting manual mode
