Analog selector
Category Signal Description
No selection No signal selected
Analog input Analog input Analog input signal
Controller Actual value Actual value on the controller input
Setpoint value Active setpoint value on the controller input
Sampling rate Sampling rate (fixed value: 150 ms)
Controller output 1 (ana-
log)
Switched controller output 1 (0 to +100 %; e.g., for
heating)
Controller output 2 (ana-
log)
Switched controller output 2 (-100 to 0 %; e.g., for
cooling)
Controller differential Difference between setpoint value and actual val-
ue of the controller
Output level display Controller output level (-100 % to +100 %)
Setpoint values Setpoint 1 to
setpoint 4
Setpoint values that can be selected through the
setpoint changeover.
Current setpoint value Setpoint value selected through the setpoint
changeover
Program setpoints Program setpoint value Current program setpoint
Program Section end value Setpoint value at the end of the program section
Section remaining run-
ning time
Remaining running time of the current program
section in seconds (remaining time)
Program remaining run-
ning time
Remaining running time of the program in seconds
(remaining time)
Section runtime Runtime of the current program section in seconds
(already elapsed time)
Program runtime Runtime of the program in seconds (already
elapsed time)
Ramp Ramp end value End value of the setpoint ramp (corresponds to the
specified setpoint value)
Current ramp setpoint
value
Current value of the setpoint ramp
Timer Timer runtime Runtime of the timer in seconds (already elapsed
time)
Timer remaining running
time
Remaining running time of the timer in seconds
(remaining time)
Timer value Set timer time in seconds
Ext. analog inputs Ext. analog input 1
ext. analog input 2
Signal of the external analog inputs 1 and 2 (via in-
terface)
Flags Analog flag 1
analog flag 2
Analog flags are analog values that can be de-
scribed and read out as well as internally pro-
cessed via the interface.
Math result Math result 1 to
math result 4
Results of the math formulae (formula 1 to formula
4)
ST analog outputs ST analog output 1 to
ST analog output 6
Signals of the analog outputs from the PLC module
(application created with ST code)
