JUMO diraTRON 108 User Manual

7 Configuration
72
Parameter Selection/text/value Description
Function Without function
AF1 Limit value above and below the setpoint value
AF2 As for AF1, output signal inverted
AF3 Limit value below the setpoint value
AF4 As for AF3, output signal inverted
AF5 Limit value above the setpoint value
AF6 As for AF5, output signal inverted
AF7 Fixed limit value (independent of the setpoint val-
ue)
AF8 As for AF7, output signal inverted
Actual value input Analog selector
No selection
Analog signal as actual value (signal to be moni-
tored)
Setpoint value input Analog selector
No selection
Analog signal as setpoint value (reference signal
for AF1 to AF6)
Limit value -1999 to 9999 (0) Admissible deviation (AL) of the actual value
Limit value 2 -1999 to 9999 (0) For non-standard limit value function: second limit
value (AL2) to implement an asymmetrical moni-
toring band; only for AF1 and AF2
The limit value (AL) is below the setpoint value; the
second limit value (AL2) is above the setpoint val-
ue.
Switching differential 0 to 9999 (1) Switching thresholds of the output signal (differ-
ence from limit value)
Switching behavior
(setup only)
Switching differential position around the limit val-
ue
Standard Switching differential is positioned with half above
and half below the limit value.
Non-standard left Switching differential is below the limit value (typi-
cally).
Non-standard right Switching differential is above the limit value (typi-
cally).
Limit value function
(setup only)
Standard of monitoring band for AF1 and AF2
Standard Standard monitoring band, formed by the limit val-
ue (AL)
Non-standard Non-standard monitoring band, formed by the limit
value (AL) and limit value 2 (AL2)
Startup alarm suppres-
sion
Alarm suppression during start-up phase
Off Limit value monitoring always operates according
to its alarm function.
On Alarm suppression after power on or if limit value
or setpoint value is changed
Response in case of a
fault
Output signal in the event of a fault (e.g., in the
event of overrange or underrange)
Off Output signal inactive
On Output signal active
Switch-on delay
(setup only)
0 to 9999 Delay time (in seconds) for activation of the output
signal if alarm condition is present.
?
?
?
?
