JUMO diraTRON 108 User Manual

7 Configuration
52
Unit
(setup only)
<Enter text>
%
Value unit (if it is not a temperature)
Resistance measuring
range
0...400 Ω
0...4000 Ω
Measuring range for resistance/potentiometer and
RTD temperature probe with customer-specific lin-
earization
Resistance Ra or R0 0 to 4000 (Ω) For resistance transmitter: Resistance Ra between
slider (S) and start (A), if the slider is positioned at
the start.
For resistance/potentiometer: Offset resistance Ro
Resistance Rs or Rx 0 to 4000 (1000) (Ω) For resistance transmitter: Resistance range Rs of
the slider
For resistance/potentiometer: Shifting resistance
range Rx
Resistance Re 0 to 4000 (Ω) For resistance transmitter: Resistance Re between
slider (S) and end (E), if the slider is positioned at
the end.
Scaling start -1999 to 9999 (0) Lower limit of measuring range or display range
(depending on sensor and linearization)
Scaling end -1999 to 9999 (100) Upper limit of measuring range or display range
(depending on sensor and linearization)
Decimal places Number of pre-decimal and decimal places for the
numerical display of the measured value
Auto Automatic
XXXX. No decimal place
XXX.X One decimal place
XX.XX Two decimal places
X.XXX Three decimal places
Measured value offset -1999 to 9999 (0) Correction value for the measured value
All measured values are moved by the same cor-
rection value (see fine adjustment).
Filter time constant 0 to 100 (0.6) Time constant (in seconds) for adjusting the digital
input filter (0 s = filter off)
KTY at 25 °C
(setup only)
0 to 4000 (2000) For 2-L RTD temperature probe with linearization
KTY11-6 2-L: resistance (in Ω) at 25 °C / 77 °F
Cold junction tempera-
ture
(setup only)
Only with thermocouple: selection of the cold junc-
tion temperature
Internal Internal temperature is used.
Constant Constant temperature can be entered.
Constant
(setup only)
0 to 100 (25) Constant cold junction temperature
Fine adjustment
(device only)
Off The function for performing fine adjustment is not
active.
This function is available in the setup program un-
der "Online parameter".
On The function is active.
Parameter Selection/text/value Description
?
?
?
?
?
